Drolet Spark II Wood Stove - DB03401

Call for availability
SKU: DB03401
filler

Price:
Sale price$1,175.00

Description

Drolet Spark II Wood Stove - DB03401

Amongst the most compact on the market, our Spark II wood stove can heat ​​up to 1,200 ft² with a maximum heat output of 45,000 BTU/h. Non-catalytic and EPA certified at 1.8 g/h, this model can efficiently heat small spaces. The bottom of its combustion chamber is deeper than other models in its category and allows a greater accumulation of ashes, and thus to be able to empty them much less frequently. Packaged in a rigid cardboard box for ease of transport, this appliance requires simple assembly.

Included: steel legs, air deflector, ceramic glass, cast iron door with adjustable hinges, ash lip, air damper

FEATURES:

Heating area 250 - 1,200 Ft2
Size 18 1/2" W X 28 7/8" D X 28 3/4" H
Maximum log length 17"
Average particulate emission rate
1.8 g/h

  • Up to 5 hours burn time
  • Up to 17" logs
  • 1.55 ft³ firebox
  • EPA certified
  • Proudly made in Canada
  • Limited lifetime warranty
  • Certified for mobile home and alcove installation

SPECIFICATIONS:

General Features:

Combustion technology Non-catalytic
High-efficiency certified appliance Yes, EPA 2020 approved
Maximum log length 17"
Log positioning Loading over depth
Chimney diameter 6"
Flue outlet diameter 6"
Type of chimney CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet) 12'
Baffle type High quality vermiculite
Approved for an alcove installation Yes
Approved for a mobile home installation Yes, with fresh air intake
Shipping Weight 230 lb
Door type Single, glass with cast iron frame
Glass type Ceramic glass
Glass surface – dimensions (Width X Height) 10 1/4" X 8 1/2"
Glass air-wash system Yes
Overall dimension (Height) 28 3/4"
Overall dimension (Width) 18 1/2"
Overall dimension (Depth) 28 7/8"
Door opening – dimension (Height) 7 5/8"
Door opening - dimension (Width) 12"
Firebox – dimension (Height) 11 3/4"
Firebox – dimension (Width) 14 1/4"
Firebox – dimension (Depth) 19 1/8"
Firebox lined with refractory bricks for better heat distribution Yes
Stainless-steel secondary-air system improving gas combustion Yes
Steel thickness – body 3/16"
Steel thickness – top 1/4"
USA standard (emissions) EPA
Canadian Standard (emissions) CSA B415.1-10
USA standard (safety) UL 1482, UL 737
Canadian standard (safety) ULC S627
Tested and listed as per applicable standards By an accredited laboratory (CAN/USA)
Warranty Limited lifetime



 Appliance Performance:

Fuel type Dry cordwood (16" recommended)
Recommended heating area(9) 250 - 1,200 ft²
Overall firebox volume 1.8 ft³
EPA loading volume 1.55 ft³
Maximum burn time(9) 5 h
Maximum heat output-dry cordwood(4) 45,000 BTU/h (13.19 kW)
Minimum overall heat output rate(4) (5) 12,124 BTU/h (3.55 kW)
Maximum overall heat output rate(4) (5) 26,700 BTU/h (7.83 kW)
Average overall efficiency-dry cordwood (HHV)(5) (6) 74 %
Average overall efficiency-dry cordwood (LHV)(5) (7) 79 %
Optimum efficiency(1) (2) 80 %
Optimum heat transfer efficiency(8) 79 %
Average particulate emission rate(3) 1.8 g/h
Average CO(10) 74 g/h
Size Small
Maximum log length 17"
Shipping weight 235 lb (107 kg)
Overall dimension (Width) 18 1/2"
Overall dimension (Height) 28 3/4"
Overall dimension (Depth) 28 7/8"
Warranty Limited lifetime
Alcove installation approved Yes
Mobile home approved Yes, with fresh air intake
Certified according to applicable standards By an accredited laboratory (CAN/USA)
Premium quality blower included (CFM) Optional
Combustion technology Non-catalytic

(1) This appliance is officially tested and certified by an independent agency.

(2) Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

(3) The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³ and reloading intervals ranging from 60 to 120 minutes. Other performances are based on a fuel load prescribed by the standard without any reloading between start and finish. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

(4) As measured per CSA B415.1-10 stack loss method.

(5) Higher Heating Value of the fuel.

(6) Lower Heating Value of the fuel.

(7) Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

(8) Optimum overall efficiency at a specific burn rate (LHV).

(9) The optimum heat transfer efficiency is for the low burn rate (using HHV) and represents the appliance’s ability to convert the energy contained in the wood logs into energy transferred to the room in the form of heat and does not take into account the chemical losses during combustion.

(10) Carbon monoxyde.

Clearances:

  United-States
  Single wall pipe Double wall pipe
Clearance – back wall 12" 6"
Clearance - corner 11" 7"
Clearance – side wall 18" 18"
Clearance – top (measured from the platform on which the appliance is installed)** 84" 84"
