Empire Comfort Systems 36" Direct Vent, IP, Barrier - DVL36BP70N

Call for availability
SKU: DVL36BP70N
filler

Gas Type: Natural Gas
Price:
Sale price$2,549.00

Description

Empire Comfort Systems 36" Direct Vent, IP, Barrier - DVL36BP70N

A Direct-Vent system uses two vent pipes. One draws air in from outdoors to support combustion. The other exhausts the by-products of combustion to the outside. The two vent pipes may be concentric (exhaust pipe within a larger diameter intake pipe) or co-linear (separate pipes of about the same size).

Combustion takes place inside a sealed chamber – with a glass front in the
case of a fireplace. Room air circulates around the combustion chamber, often assisted by a blower, to heat the room.

A DV system is often installed along an outside wall to simplify the vent run,
but can also be installed elsewhere in the home and vented through the roof.

FEATURES:

  • Size: 36 Inches(DVL36BP70P, DVL36BP70N)
  • Color: Black(DVL36BP70P, DVL36BP70N)
  • Product Dimensions: 49 3/4" W x 31 7/16" H x 15" D(DVL36BP70P, DVL36BP70N)
  • Tempered glass
  • Modern, linear style
  • Mobile home approved
  • On/off switch with 10 foot wire
  • Includes clear crushed glass media

SPECIFICATIONS:

  • Maximum BTU Output: 25,000
  • Min/Max Natural Gas Inlet Pressure: 4.5"/14" WC
  • Min/Max Propane Inlet Pressure: 11"/14" WC
  • Framing Dimensions: 48 1/4" W x 34 1/8" H x 16" D
  • Venting Dimensions: 4" ID, 6 5/8" OD
  • Actual Viewing Area: 32 7/16" W x 13" H
  • Valve Type: IPI (intermittent pilot)

ADVANTAGES:

  • Good efficiency – 60 to 80%
  • Good heat output with thermal transfer through the glass and air circulation
  • Separates room air from combustion air
  • May be used as primary heat source
  • Can operate with a remote or thermostat
  • Most systems can provide live-saving heat during a winter power outage
  • Choose fireplace, insert, cast iron stove, or heater
